T-8A CARTRIDGE VALVE BODY & HOUSING

/T-8A Cartridge Valve Body, Integrated Block CB1
T-8A Cavity Block PDF

Cartridge Valve Body CB1 Series: T-8A Cavity, Cartridge Valve Housing

Feature:
* 2 Types of flow rate for optional, with different size of connection threads
* Max. Pressure: Aluminum up to 207bar/3000psi, Steel up to 350bar/500psi
* Threaded Connection: SAE ; NPT ;  BSPP for optional

T-8A Cartridge valve body is manufacturing in aluminum materials, high strength carbon steel, or cast iron, modular or cartridge valve is available to mount on the hydraulic valve block. T-8A Hydraulic cartridge valve block is design for hydraulic screw-in valve, threaded connection standard or custom cavity, SAE, ISO, BSP, BSPP, BSPT, METRICE threads available for customer option.
There many different functions of cartridge valves are available to be integral in hydraulic valve block, such as solenoid cartridge valves, pressure relief valve or cartridge flow control valves. The Max. pressure of hydraulic valve block is up to from 210 to 315bar as per the raw materials of block and cartridge valve characteristics.
Technical Information Of Hydraulic Cartridge Valve Block:
Main Raw Materials: Alloy aluminum(6061/7075-T6), 45# steel or casting Iron
Power: By hydraulic fluid
Brand: Finotek or OEM
Max. Operation Pressure: 21Mpa ~ 31.5Mpa
Valve cavity type: T-8A Cavity
Oil Medium Temperature: -30 to +80(°C)for NBR O-rings
Oil Medium: Mineral oil as per DIN51 524, VDMA 24 568 or rapeseed oil, Viscosity 10 – 400 CST
Recommended Medium Filtration: ISO 4406 Standard, cleanliness class:20/18/15
Hydraulic Subplate Surface Treatment:
Steel= Black galvanized or zinc plated
Alloy Aluminum= Aluminum oxidation

T-8A Cartridge Valve Body Ordering Code:

T-8A Cartridge Valve Body Ordering Code

T-8A Cartridge Valve Body Dimensions:

T-8A Cartridge Valve Body Dimensions
